ETO STERILIZER

Get a Price/Quote

MOQ : 1 Unit

ETO STERILIZER Specification

Type
Horizontal Rectangular

Chamber Size
1200 x 600 x 600 mm

Chamber Thickness
5 mm

Outer Size
2250 x 1200 x 1500 mm

Compressed Air
6 Bar Required

Door Type
Single / Double Hinged Door

Design Pressure
2.5 Bar

Working Pressure
1.2 Bar

Design Temperature
60C

Heat Uniform
2C

Insulation
High Density Mineral Wool

Net Weight
1450 kg

Recording Parameters
Temperature, Pressure, Humidity

Spraying Mode
Automatic/Manual

Outer Trolley
304 Stainless Steel Construction

Inner Trolley
304 Stainless Steel Perforated

Spraying Piping
316 Stainless Steel, Bored Holes

Steam
5.5 Bar Required

Sterilizing Temperature
37C to 55C

Working Temperature
Up to 55C

Sterilization Time
2 to 8 Hours (Adjustable)

Temperature Scope
Room Temperature to 60C

Piping System
Stainless Steel with Automatic Control Valves

Valves
Pneumatic/Automatic SS Valves

Power Consumption
7.5 kW

Gas Injection
Automatic ETO Gas Injection System with Interlocks

Exhaust System
Automatic ETO Gas Neutralizer with Activated Carbon

Sealing Gasket
Silicone Food Grade

Control System
PLC Based Fully Automatic with HMI

Cycle Documentation
Printer/USB Data Recorder

Safety Features
Door Safety Interlocks, Low/High Temperature Protection, Gas Leak Detection

Heating Mode
Electric Heaters with PID Control

Chamber Surface Finish
Mirror Polish

Vacuum System
Heavy Duty Vacuum Pump with Backup

Service Access
Front/Side Access Panels for Maintenance

Material of Construction
Entirely 304/316 Stainless Steel for Chamber and Piping

Installation
Skid Mounted, Plug & Play

ETO STERILIZER Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Month

Delivery Time
7 Days

About ETO STERILIZER

Discover the Elite ETO Sterilizer-an engineering marvel crafted from 304/316 stainless steel for unparalleled durability and hygiene. Order today to experience a PLC-based, fully automatic control system with a user-friendly HMI. This remarkable device features automatic ETO gas injection with interlocks, advanced safety mechanisms including gas leak detection, and cycle documentation via printer or USB recorder. Featuring a heavy-duty vacuum system, mirror-polished chamber, and plug-and-play installation, the ETO Sterilizer stands tall as a noteworthy solution for modern sterilization needs. Get it now and elevate your facility's sterilization standards.

ETO STERILIZER: Versatile Applications and Distinctive Features

The ETO Sterilizer is expertly engineered for hospitals, laboratories, medical device manufacturers, and pharmaceutical industries. Its usage spans sterilization of heat-sensitive equipment, plastic wares, and delicate instruments. Noteworthy features include a horizontal rectangular design, adjustable sterilization cycles, high-density mineral wool insulation, and pneumatic stainless steel valves. Designed for both small-scale and large-scale use, this unit boasts dual door options, food-grade silicone sealing, and advanced cycle recording, making it suitable for elevated demand and stringent compliance environments.

ETO STERILIZER: Efficient Supply, Payment Options, and Domestic Reach

Enjoy a reliable supply ability with prompt logistics support focusing on swift order processing. List price is provided upon inquiry, and flexible payment terms are available for a seamless purchase experience. Once your order is placed, the ETO Sterilizer is carefully dispatched across India's main domestic markets, supported by robust after-sales service. This proactive delivery model ensures customers get their elite sterilization solution without unnecessary delays, offering both convenience and security throughout the transaction process.

FAQ's of ETO STERILIZER:

Q: How does the automatic ETO gas injection system work in this sterilizer?

A: The automatic ETO gas injection system ensures precise and safe delivery of sterilant gas into the chamber, with built-in interlocks to prevent leaks and ensure optimal sterilization cycles for reliable results.

Q: What safety features are included in the ETO Sterilizer?

A: Safety features include door safety interlocks, low/high temperature protection, gas leak detection, and an automatic ETO gas neutralizer with activated carbon to protect users and the environment.

Q: When is the ETO Sterilizer typically used in healthcare and industry?

A: The ETO Sterilizer is used when sterilizing heat-sensitive instruments and materials in hospitals, laboratories, medical device manufacturing, and pharmaceutical environments, especially for tools that cannot endure high-temperature steam.

Q: Where can the ETO Sterilizer be installed, and what are its access options?

A: This skid-mounted system allows flexible installation in various clinical and industrial environments, offering plug-and-play set-up and convenient front/side access panels for routine maintenance.

Q: What is the process for cycle documentation and data recording?

A: Cycle documentation is seamless with a built-in printer or USB data recorder, capturing key parameters like temperature, pressure, and humidity throughout the sterilization process for regulatory compliance.

Q: What are the benefits of using a PLC-based fully automatic control system?

A: A PLC-based fully automatic control system streamlines operation, reduces manual intervention, increases accuracy in cycle management, and enhances user convenience through an intuitive HMI interface.
