HOSPITAL AUTOCLAVE

Get a Price/Quote

MOQ : 1 Unit

HOSPITAL AUTOCLAVE Specification

Type
Horizontal rectangular autoclave

Chamber Size
600 x 600 x 1200 mm

Chamber Thickness
6-8 mm high tensile SS 316

Outer Size
900 x 1100 x 1700 mm

Compressed Air
0.6 - 0.8 MPa

Door Type
Horizontal sliding, automatic and manual double door

Design Pressure
0.25 MPa

Working Pressure
0.22 MPa

Design Temperature
139C

Heat Uniform
1C

Insulation
High-density glass wool

Net Weight
Approx. 750 kg

Recording Parameters
Digital printer for temperature, pressure, time

Spraying Mode
Multi-angle, pressure spraying

Outer Trolley
Available, stainless steel construction

Inner Trolley
Available, perforated for optimal steam penetration

Spraying Piping
Stainless steel, corrosion resistant

Steam
Saturated, external source

Sterilizing Temperature
121C

Working Temperature
105C - 134C

Sterilization Time
20-60 min adjustable

Temperature Scope
105C - 134C

Piping System
316L stainless steel, pharmaceutical grade

Valves
Safety, exhaust, steam inlet, vacuum

Power Consumption
8-12 kW

Drainage System
Bacterial filter equipped

Sterilant
Pure saturated steam

Display
Digital multifunction display

Safety Features
Door interlock, pressure safety valve, emergency stop

Service Access
Frontal and side panels for easy maintenance

Vacuum System
Liquid ring pump

Control System
PLC microprocessor-based with touchscreen HMI

Noise Level
65 dB(A) during operation

Color/Finish
Matte, stainless steel polish

Conformity
Meets ISO 13485, CE certified

Water Circulation
Automated with separate reservoir

Gasket Type
Inflatable silicone, automatic sealing

Process Recording
USB interface for data storage

Chamber Material
High grade stainless steel SS 316L

Door Gasket
Food grade silicon, inflatable type

HOSPITAL AUTOCLAVE Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Month

Delivery Time
7 Days

About HOSPITAL AUTOCLAVE

Last Chance to secure this rare Hospital Autoclave, meticulously engineered for towering sterilization demands. Featuring a lavish chamber of high-grade SS 316L and a PLC microprocessor control system, its inestimable capabilities are further marked down for a limited period. The advanced vacuum system, automated water circulation, and inflatable door gasket ensure secure and efficient cycles. With ISO 13485 compliance and CE certification, this matte-finish, dual-door autoclave offers pristine, bacterial-free results while maximizing safety through its integrated features. Seize this unique opportunity for a state-of-the-art unit.

Hospital Autoclave: Application, Features, and Usage

This Hospital Autoclave is designed for sterile processing in hospitals, pharmaceutical plants, and research laboratories. Its key features include a spacious chamber of 600 x 600 x 1200 mm, PLC microprocessor with touchscreen HMI, and automated, programmable sterilization cycles (121C for 20-60 minutes). The system delivers precise steam sterilization, using an inflatable silicone gasket for sealed operations and multi-angle pressure spraying for thorough coverage, supporting critical medical equipment sterilization, laboratory glassware, and surgical instruments.

Payment Terms, Delivery, and Packaging for Hospital Autoclave

To leverage the market value and secure this autoclave below typical list price, payment terms can be negotiated based on your institution's purchasing protocols. Delivery time ranges from 4 to 6 weeks after order confirmation, ensuring prompt handover for urgent needs. Each unit is robustly packaged in export-quality wooden crates with detailed installation manuals and accessories to ensure safe transportation and immediate usability upon arrival at your site.

FAQ's of HOSPITAL AUTOCLAVE:

Q: How does the Hospital Autoclave ensure reliable sterilization?

A: The autoclave employs pure saturated steam and multi-angle pressure spraying, guaranteeing inestimable sterilization efficiency across diverse equipment. The process is controlled via PLC microprocessor technology, ensuring accurate, programmable conditions.

Q: What safety features are included in the Hospital Autoclave?

A: It is equipped with a door interlock, pressure safety valve, emergency stop, and bacterial filter for drainage, all designed for operator safety and infection control. The inflatable silicone door gasket ensures a tight automatic seal.

Q: Where can this autoclave be applied most effectively?

A: This unit is ideally suited for hospitals, pharmaceutical manufacturing, research institutes, and laboratories requiring reliable large-capacity sterilization of medical instruments and laboratory equipment.

Q: What is the process for recording and retrieving sterilization data?

A: Process parameters, including temperature, pressure, and time, are automatically recorded by a digital printer and can also be transferred via USB for detailed batch tracking and regulatory compliance.

Q: What benefit does the outer and inner trolley system provide?

A: The stainless steel outer and perforated inner trolleys ensure optimal steam penetration and facilitate safe loading and unloading of instruments while enhancing workflow efficiency.
